Total TAC2144503 Diamond disc for floor saw 450mm(18″)X25.4mm(1″)
KSh18,999.00
Key Features & Applications
-
Laser-Welded Segment Core: High-strength laser welding fuses the diamond segments directly to the heavy-gauge steel body, offering maximum joint integrity under thermal stress and heavy torque.
-
Large-Diameter Floor Saw Design: Built with a standard 25.4mm (1″) center arbor and drive-pin positioning hole to prevent slippage on high-power petrol or diesel walk-behind road cutters.
-
Deep Keyhole Gullets: Wide gullet slots enable rapid slurry evacuation, promote continuous water flow cooling, and maintain high cutting speeds in deep kerf cuts.
-
Heavy-Duty Road Work & Slab Cutting: Purpose-built for cutting cured concrete slabs, asphalt surfaces, reinforced concrete floors, expansion joints, and pre-cast concrete panels.
TOTAL TAC2144503 is a heavy-duty 450mm (18″) Diamond Cutting Disc for Floor Saws, specially engineered for deep joint cutting, asphalt trenching, road maintenance, and heavy concrete slab sawing using walk-behind floor saws.
Technical Specifications
| Parameter | Specification |
| Model Code | TAC2144503 |
| Brand | TOTAL Tools |
| Disc Diameter | 450 mm (18 inches) |
| Bore / Arbor Size | 25.4 mm (1 inch) with Pin-Hole Drive |
| Manufacturing Technology | Laser Welded Diamond Segments |
| Segment Type | Keyhole / Deep-Segmented Rim |
| Segment Height | 10 mm – 12 mm |
| Segment Thickness | ~3.8 mm – 4.0 mm |
| Cutting Mode | Wet Cutting (Recommended) & Heavy-Duty Dry Cutting |
| Max Operating Speed | ~3,400 RPM (80 m/s) |
| Compatible Tools | Walk-Behind Floor Saws, Petrol Road Cutters & Heavy Saw Machines |
| Packaging | Heavy-Duty Protective Carton / Color Box |
